Production Capacity 45-1940t/h
Output Size 0-3mm, 20-40mm, 25-35mm, 40-70mm, 40-80mm,
Processing material： basalt, bank gravel
PYB 600, PYB 900, PYB 1200 often can be chosen by our customer.
15-50t/h, 50-150t/h, 160-300t/h, 300-700t/h are the hot-sale capacity
The diameter of the crushing cone is including 914mm, 1395mm, 1676mm, 2134mm.
100% factory price and maxmium discount for you is our promise. You can find our customers in more than 90 countries such as South Africa, Kenya, Nigeria, Ethiopia, Zambia, Namibia, Somalia, Nepal, Pakistan, Philippines, Malaysia, Saudi Arabic and the others.
If you are new in this industry, we will provide professional suggestions and solutions for you.
Dear, there are 3 ways for you to get the price list or quotation asap.
1. Leave your requirement to us on the message board.
2. Contact the online customer service.
3. Send an email to [email protected]
| Model | Cavity Type | Feeding Size(mm) | Closed side feeding size(mm) | Minimum Discharge Opening (mm) | Motor Power(kw) | Capacity（t/h） | Weight (t) |
| HP100 | C1 Extra coarse | 175 | 140 | 19 | 4P 100 | 45-140 | 8.4 |
| C2 Coarse | 125 | 105 | 13 | ||||
| M Medium | 100 | 70 | 10 | ||||
| F1 Fine | 71 | 50 | 9 | ||||
| F2 Extra fine | 33 | 20 | 6 | ||||
| HP200 | C2 Coarse | 235 | 190 | 19 | 4P 160 | 90-250 | 10.4 |
| M Medium | 171 | 120 | 16 | ||||
| F1 Fine | 150 | 95 | 13 | ||||
| F2 Extra fine | 116 | 70 | 8 | ||||
| HP300 | C1 Extra coarse | 265 | 230 | 25 | 4P 220 | 115-440 | 18.1 |
| C2 Coarse | 240 | 210 | 20 | ||||
| M Medium | 190 | 150 | 15 | ||||
| F1 Fine | 145 | 105 | 11 | ||||
| F2 Extra fine | 120 | 80 | 8 | ||||
| HP400 | C1 Extra coarse | 360 | 290 | 30 | 4P 315 | 140-630 | 25 |
| C2 Coarse | 310 | 250 | 25 | ||||
| M Medium | 260 | 196 | 20 | ||||
| F1 Fine | 182 | 110 | 13 | ||||
| F2 Extra fine | 135 | 90 | 10 | ||||
| HP500 | C1 Extra coarse | 370 | 330 | 38 | 4P 400 | 175-790 | 36 |
| C2 Coarse | 320 | 290 | 28 | ||||
| M Medium | 245 | 210 | 22 | ||||
| F1 Fine | 180 | 130 | 13 | ||||
| F2 Extra fine | 150 | 95 | 10 | ||||
| HP800 | C1 Extra coarse | 450 | 352 | 38 | 4P 830 | 260-1200 | 68.5 |
| C2 Coarse | 373 | 298 | 32 | ||||
| M Medium | 340 | 275 | 25 | ||||
| F1 Fine | 280 | 230 | 16 | ||||
| F2 Extra fine | 235 | 150 | 10 |
| Model | 6mm | 8mm | 10mm | 13mm | 16mm | 19mm | 22mm | 25mm | 32mm | 38mm | 45mm | 51mm |
| HP100 | 45-55 | 50-60 | 55-70 | 60-80 | 70-90 | 75-95 | 80-100 | 90-115 | 100-150 | |||
| HP200 | 65-85 | 90-125 | 110-150 | 135-180 | 150-195 | 160-210 | 170-225 | 190-235 | 210-250 | |||
| HP300 | 85-120 | 115-140 | 150-185 | 180-220 | 200-240 | 220-260 | 235-290 | 250-320 | 300-380 | 350-440 | ||
| HP400 | 135-180 | 190-230 | 225-275 | 250-320 | 270-350 | 295-380 | 290-375 | 355-490 | 410-565 | 460-625 | ||
| HP500 | 200-250 | 230-290 | 280-350 | 320-400 | 345-430 | 370-460 | 405-535 | 445-605 | 510-700 | 580-790 | ||
| HP800 | 265-340 | 320-425 | 385-510 | 425-540 | 470-605 | 495-740 | 545-800 | 600-945 | 690-1050 | 785-1200 |
